ASUS PRIME Z790-P WIFI Motherboard

ASUS PRIME Z790-P WIFI

A clean, well-cooled Z790 board for 14th and 13th Gen Intel Core builds, with a 14+1 DrMOS power stage array, four DDR5 slots and three PCIe 4.0 M.2 sockets under heatsinks. PCIe 5.0 graphics support, 2.5Gb Ethernet and a 20Gbps USB Type-C port cover everything a mainstream gaming or workstation rig needs. Supplied brand new and sealed in its original manufacturer packaging.

📋 Specifications

• Socket: Intel LGA1700 for Intel Core 14th & 13th Gen Processors
• Chipset: Intel Z790
• Form Factor: ATX — 30.5 cm x 23.4 cm
• Memory: 4 x DIMM, DDR5, max. 192GB, up to 7200+ MHz (OC), dual channel with XMP
• Power Design: 14+1 DrMOS power stages with DIGI+ VRM
• Expansion Slots: 1 x PCIe 5.0 x16 (CPU), 3 x PCIe 4.0 x16 (x4 mode), 1 x PCIe 3.0 x1
• M.2 Storage: 3 x M.2 PCIe 4.0 x4 (M.2_3 also supports SATA mode)
• SATA: 4 x SATA 6Gb/s
• LAN: Realtek 2.5Gb Ethernet
• Wireless: Wi-Fi 6 (802.11ax) 2x2, Bluetooth v5.2
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
• Rear I/O: 1 x HDMI, 1 x DisplayPort, 1 x USB 3.2 Gen 2x2 Type-C, 1 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 1 Type-A, 4 x USB 2.0 Type-A
• Colour: Black

⚡ Key Features

• Z790 chipset on LGA1700 for Intel Core 14th and 13th Gen processors.
• 14+1 DrMOS power stages with DIGI+ VRM hold voltage steady when a high-end Core i7 or i9 stretches its legs.
• Four DDR5 slots accept up to 192GB and tune to 7200+ MHz with a one-click XMP profile.
• PCIe 5.0 x16 straight from the CPU future-proofs the graphics slot.
• Three heatsinked PCIe 4.0 x4 M.2 sockets keep NVMe drives cool enough to hold peak speeds.
• USB 3.2 Gen 2x2 Type-C on the rear delivers 20Gbps to external SSDs and docks.
• Realtek 2.5Gb Ethernet plus 2x2 Wi-Fi 6 and Bluetooth 5.2 for fast wired and wireless links.
• HDMI and DisplayPort outputs run Intel integrated graphics directly.
• Four SATA 6Gb/s ports keep existing drives and optical units in the build.
• Standard ATX size drops straight into any mainstream mid-tower chassis.

🛡️ SQUADRIG Assurance

• Brand new and sealed in original manufacturer packaging
• Sourced from authorised local distributors
• Checked on arrival and securely packed for delivery
• Honest listings — specifications are taken from the manufacturer's own published data

🔑 Product Details

• Brand: ASUS
• Model: PRIME Z790-P WIFI
• Condition: Brand new
• SKU: MOH-ASUS-Z790-NEW-0909
