ASUS B850 MAX GAMING WIFI W AMD B850 ATX Motherboard

ASUS B850 MAX GAMING WIFI W AMD B850 ATX Motherboard

A white full-size AM5 board built for a modern Ryzen gaming rig, pairing PCIe 5.0 graphics and storage with Wi-Fi 6E, 2.5Gb Ethernet and 10Gbps USB Type-C. Supplied brand new and sealed in its original manufacturer packaging.

📋 Specifications

• Socket: AMD Socket AM5
• CPU support: AMD Ryzen 9000, 8000 and 7000 Series desktop processors, up to 170W TDP
• Chipset: AMD B850
• Memory: 4 x DIMM, DDR5, up to 256GB, dual channel, up to 8000+ MT/s (OC) with Ryzen 9000/8000/7000, AMD EXPO and ASUS AEMP support
• Graphics slot: 1 x PCIe 5.0 x16 with Ryzen 9000/7000 (PCIe 4.0 x16 in x8/x4 mode with Ryzen 8000)
• Additional slots: 1 x PCIe 4.0 x16 (x4 mode), 2 x PCIe 3.0 x16 (x1 mode) from the chipset
• M.2 storage: 3 x M.2 — M.2_1 PCIe 5.0 x4 (Ryzen 9000/7000), M.2_2 PCIe 4.0 x4/x2, M.2_3 PCIe 4.0 x2 (2242/2260/2280/22110)
• SATA: 4 x SATA 6Gb/s
• LAN: 1 x Realtek 2.5Gb Ethernet with ASUS LANGuard
• Wireless: Wi-Fi 6E 2x2 (802.11ax) 2.4/5/6GHz, Bluetooth v5.3
• Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC, 24-bit/192 kHz
• Rear USB: 4 x USB 10Gbps (3 x Type-A, 1 x Type-C), 2 x USB 5Gbps, 2 x USB 2.0
• Rear video outputs: 1 x DisplayPort (8K@30Hz), 1 x HDMI (4K@60Hz)
• Other rear I/O: 3 x audio jacks, 1 x BIOS FlashBack button
• BIOS: 256 Mb Flash ROM, UEFI AMI BIOS with CrashFree BIOS 3 and EZ Flash 3
• Form factor: ATX, 30.5 cm x 24.4 cm (12 in x 9.6 in)
• Colour: White PCB

⚡ Key Features

• Socket AM5 with AMD B850 supports Ryzen 9000, 8000 and 7000 Series processors up to 170W, so a high-core-count chip drops straight in.
• Four DDR5 slots take up to 256GB and push past 8000 MT/s when overclocked, with AMD EXPO and ASUS AEMP profiles for one-click memory tuning.
• A PCIe 5.0 x16 graphics slot on Ryzen 9000 and 7000 processors leaves plenty of bandwidth for current and next-generation graphics cards.
• Three M.2 sockets, the first running at PCIe 5.0 x4, let you build a fast boot drive plus two more NVMe SSDs without touching the SATA ports.
• Four SATA 6Gb/s ports remain free for bulk hard drives or an existing SSD library.
• Realtek 2.5Gb Ethernet with LANGuard plus Wi-Fi 6E 2x2 and Bluetooth 5.3 cover fast wired play and clean 6GHz wireless.
• Rear USB 10Gbps Type-C alongside three 10Gbps Type-A, two 5Gbps and two USB 2.0 ports keeps peripherals and fast external drives connected.
• DisplayPort up to 8K@30Hz and HDMI at 4K@60Hz drive a display directly from a Ryzen processor with integrated graphics.
• BIOS FlashBack lets you update firmware for a newer CPU without a processor or memory installed — useful for a fresh build.
• White PCB in a full ATX 30.5 x 24.4 cm layout suits light-themed builds and standard mid-tower cases.

🛡️ SQUADRIG Assurance

• Brand new and sealed in original manufacturer packaging
• Sourced from authorised local distributors
• Checked on arrival and securely packed for delivery
• Honest listings — specifications are taken from the manufacturer's own published data

🔑 Product Details

• Brand: ASUS
• Model: B850 MAX GAMING WIFI W
• Condition: Brand new
• SKU: MOH-ASUS-B850-NEW-0911
